7305A5hU9 Cryogenic bearings

The 7305A5hU9 produced by MONTON is a low temperature pump bearing with core parameters consistent with the conventional angular contact ball bearing 7305 series, but specially designed for extreme working conditions. Specially designed for low temperature environments (such as liquid nitrogen and liquid helium working conditions), using special materials and heat treatment processes to ensure stable operation within the range of -256 ℃. 7305A5hU9 has a high maximum speed and is suitable for high-speed equipment such as cryogenic pumps, turboexpanders, and rocket turbopumps. If you need further technical parameters, you can directly contact MONON for detailed specifications.

Case Details

Name	Cryogenic bearings
Seires	73 series
Brand	MONTON
Model	7305A5hU9/S7305
d	25mm
D	62mm
B	17mm
Ring Material	Special steel
Cage Material	PTFE
Load rating Cr	24kN
Load rating Cor	14kN
Sealed	N/A
Weight	0.23KG
Design Structure	Angular Contact
Precision	P4
Quality standard	ISO9001: 2000/SGS RoHS ect.
Package	single box
Original	Luoyang
Service	OEM
Delivery date	Stock
Application	LNG pump Cryogenic pum LOX Turbo Pump Rocket engine Rocket cryogenic liquid pump Spacecraft liquid pump
