RE Type Crossed Roller Bearings

RE Crossed Roller Bearings

  • RE Crossed Roller Bearings is a roller bearing with split inner ring and integrated outer ring. It's a bearing with outer ring rotating structure. The main dimensions of RE cross roller bearing are the same as those of RB type cross roller bearing. It is suitable for parts requiring outer ring rotation accuracy. RE type fork roller bearing has high rigidity and high running accuracy of guide roller by optimizing preload. It is suitable for parts requiring high outer ring rotation accuracy. The thin-walled size miniaturization design is conducive to the lightweight design of related structures. The overall structure of the outer ring is more suitable for occasions with high outer ring rotation accuracy, and the stable rotation accuracy reaches μm level.
Product Details

Bearings

Dimension

Basic Load Rating (Radial)

Weight

Inner Diameter

Outside Diameter

Pitch Diameter

Width

C
kN

Co
kN

kg

d

D

dp

B B1

RE2008

20

36

29

8

3.23

3.1

0.04

RE2508

25

41

34

8

3.63

3.83

0.05

RE3010

30

55

43.5

10

7.35

8.36

0.12

RE3510

35

60

48.5

10

7.64

9.12

0.13

RE4010

40

65

53.5

10

8.33

10.6

0.16

RE4510

45

70

58.5

10

8.62

11.3

0.17

RE5013

50

80

66

13

16.7

20.9

0.27

RE6013

60

90

76

13

18

24.3

0.3

RE7013

70

100

86

13

19.4

27.7

0.35

RE8016

80

120

101.4

16

30.1

42.1

0.7

RE9016

90

130

112

16

31.4

45.3

0.75

RE10016

100

140

121.1

16

31.7

48.6

0.83

RE10020

100

150

127

20

33.1

50.9

1.45

RE11012

110

135

123.3

12

12.5

24.1

0.4

RE11015

110

145

129

15

23.7

41.5

0.75

RE11020

110

160

137

20

34

54

1.56

RE12016

120

150

136

16

24.2

43.2

0.72

RE12025

120

180

152

25

66.9

100

2.62

RE13015

130

160

146

15

25

46.7

0.72

RE13025

130

190

162

25

69.5

107

2.82

RE14016

140

175

160

16

25.9

50.1

1

RE14025

140

200

172

25

74.8

121

2.96

RE15013

150

180

166

13

27

53.5

0.68

RE15025

150

210

182

25

76.8

128

3.16

RE15030

150

230

192

30

100

156

5.3

RE16025

160

220

192

25

81.7

135

3.14

RE17020

170

220

196.1

20

29

62.1

2.21

RE18025

180

240

210

25

84

143

3.44

RE19025

190

240

219

25

41.7

82.9

2.99

RE20025

200

260

230

25

84.2

157

4

RE20030

200

280

240

30

114

200

6.7

RE20035

200

295

247.7

35

151

252

9.6

RE22025

220

280

250.1

25

92.3

171

4.1

RE24025

240

300

272.5

25

68.3

145

4.5

RE25025

250

310

280.9

25

69.3

150

5

RE25030

250

330

287.5

30

126

244

8.1

RE25040

250

355

300.7

40

195

348

14.8

RE30025

300

360

332

25

75.5

178

5.9

RE30035

300

395

345

35

183

367

13.4

RE30040

300

405

351.6

40

212

409

17.2

RE35020

350

400

376.6

20

54.1

143

3.9

RE40035

400

480

440.3

35

156

370

14.5

RE40040

400

510

453.4

40

241

531

23.5

RE45025

450

500

476.6

25

61.7

182

6.6

RE50025

500

550

526.6

25

65.5

201

7.3

RE50040

500

600

548.8

40

239

607

26

RE50050

500

625

561.6

50

267

653

41.7

RE60040

600

700

650

40

264

721

29

RE Crossed roller bearings are designed to withstand radial loads, axial loads, moment loads, and other loads in all directions because their cylindrical rollers are arranged perpendicularly to each other on a 90° V-groove rolling surface through a spacer. The cross roller ring has high rigidity, so it is most suitable for the joints or rotating parts of industrial robots, the rotary table of machining centers, the rotating part of manipulators, precision rotary tables, medical machines, measuring instruments, IC manufacturing devices, etc.

Our company has professional sales and technical engineers who are responsible for providing users with technical consultation, technical services, and product technical training on precision bearing data and installation and use. Perfect pre-sales, in-sales, and after-sales services constitute a guarantee system for high-quality services, providing users with reliable quality bearing products and creating excellent user experience and rich benefits for every customer.

If you have any questions about products and services, please contact the company's service department directly.
