Ball Screw Bearings
|
Name |
Axial angular contact ball bearing |
|
Brand |
MONTON |
|
Model |
ZKLN0619-2RSP4 |
|
Other model |
ZKLN0619-2Z-XL |
|
Bore diameter |
06mm |
|
Outside diameter |
19mm |
|
B(width) |
12mm |
|
Ring Material |
Bearing steel |
|
Cage Material |
Nylon |
|
Basic dynamic load rating, axial |
5.00 N |
|
Basic static load rating, axial |
5.700 N |
|
Limiting speed for Grease lubrication |
22.800 1/min |
|
Thermally safe operating speed |
14.000 1/min |
|
Bearing frictional torque |
0,01 Nm |
|
Sealed |
as customer requested |
|
Weight |
0.018KG |
|
Quality standard |
ISO9001: 2000/SGS |
|
Package |
single box |
|
Original |
Luoyang |
|
Delivery date |
Accordingly |
|
Application |
Used in various processing equipment such as CNC machine tools, lathes, milling machines, grinders, etc |
