Angular Contact Ball Bearings
|
Name |
High speed angular contact ball bearings |
|
Seires |
BER Series |
|
Brand |
MONTON |
|
Model |
40BER19STSUELP3 |
|
Contact Angle |
25° |
|
d |
40mm |
|
D |
62mm |
|
B |
12mm |
|
Ring Material |
Gcr15/ Carbon Steel |
|
Cage Material |
Phenolic cage |
|
Load rating Cr |
11.00kN |
|
Load rating Cor |
7.35kN |
|
RPM Grease |
23600 |
|
RPM Oil |
33400 |
|
Sealed |
as customer requested |
|
Weight |
0.105KG |
|
Bearing Arrangement |
U/DB/DT/TBT/QBC/DU/QU ect. |
|
Design Structure |
Angular contact |
|
Precision |
P4,P5 or as customer requested |
|
Vibration |
ZV1, ZV2, ZV3, or as customer requested |
|
Clearance |
C0, C2, C3, or as customer requested |
|
Quality standard |
ISO9001: 2000/SGS |
|
Package |
single box |
|
Original |
Luoyang |
|
Service |
OEM |
|
Delivery date |
Accordingly |
|
Application |
Spindle ,Machine tool |
