MS21154B Aerospace bearings

Aerospace bearings are high precision and high reliability bearings used in aircraft and spacecraft, playing a crucial role in ensuring equipment attitude stability, power transmission, and motion accuracy. The aerospace bearings produced and manufactured by MONTON can meet extreme environmental conditions, including high temperature, low temperature, vacuum, high radiation, and microgravity.

Case Details

Name	Aerospace bearings
Brand	MONTON
Model	MS21154B-04
Other model	MS21154B
Bore diameter	6.35mm
Outside diameter	16.667mm
B(width)	6.35mm
Ring Material	Alloy steel/ 440C
Cage Material	Special cage
Axial Static Limit Load Bronze Race	4800N
Radial Limit Load Rating	23100 N
Axial Static Limit Load Approx. Steel Race	12455N
Bearing frictional torque
Weight	0.09KG
Quality standard	ISO9001: 2000/SGS
Package	single box
Original	Luoyang
Delivery date	Accordingly
Application	Aerospace
